L01 左舵和右舵的中型SUV(含欧盟认证)

JF-L01 SUV

<
JF- LEV01  车型参数配置表                                                                    Vehicle Model Configuration Table
230906
基本参数Basic
Parameter
英文名称
English Name
500+km FWD 500+km AWD
车型 Vehicle model JF- LEV01
车辆类别 Type SUV SUV
品牌 Brand   JunFeng
能源类型 Type of Energy BEV BEV
长*宽*高(mm) Length*Width*Height
(mm)
4640*1870*1655 4640*1870*1655
轴距(mm) Wheelbase (mm) 2760 2760
车身结构 Body Structure 5门5座SUV
SUV with Five-door and
Five-seat
5门5座SUV
SUV with Five-door and
Five-seat
最高车速(km/h) Maximum Speed(km/h) 160 160
0-100km/h加速(s) 0-100km/h Acceleration
(s)
7.7 4.3
0-100km/h制动(m) 0-100km/h Braking
distance(m)
≦38 ≦38
前轮距(mm) Front Tread(mm) 1585 1585
后轮距(mm) Read  Tread(mm) 1595 1595
满载最小离地间隙
(mm)
Minimum Ground
Clearance (mm)
160 160
最大爬坡度(%) Max Climbing (%) 35 35
最小转弯直径(m) Minimum turning
diameter (m)
11.5 11.5
后备箱容积(L) Trunk Volume (L) 450 450
整备质量(kg) Curb Weight(kg) 1880 1920
最大满载质量(kg) GVW (kg) 2255 2295


最大功率(kW) Maximum Power (kW) 150 300
最大扭矩(N.m) Maximum torque (N ·m) 320 640
电动机(Ps) E-moter(Ps) 204 408
电机类型 Motor Type 永磁/同步Permanent
magnet/synchronous
永磁/同步Permanent
magnet/synchronous
电机总功率 (kw) Total Motor Power (kw) 150 300
前电机最大功率
(kw)
Maximum Power of Front
Motor (kw)
150 150
前电机最大扭矩
(N.m)
Maximum Torque of Front
Motor (N.m)
320 320
后电机最大功率
(kw)
Maximum Power of Rear
Motor (kw)
- 150
后电机最大扭矩
(N.m)
Maximum Torque of Rear
Motor (N.m)
- 320
驱动电机数 Number of Driving
Motors
单电机Single Motor 双电机
Dual motor
电机布局 Motor Layout 前置 Front 四驱
4DW
档位数 Number of Gears 1 1
变速箱类型 Trasmission Type 电动车单速变速箱
Single gear Transmission
电动车单速变速箱
Single gear Transmission
驱动方式 Driving type FWD AWD
电池类型 Battery 磷酸铁锂
LiFePo
磷酸铁锂
LiFePo
NEDC纯电续航里程
(km)
NEDC (km) 500+ 500+
快充时间(小时) Fast Charge Time (h) 0.5 0.5
慢充时间(小时) Slow Charge Time (h) 9 9
快充电量百分比 Fast Charge Percentage 80%SOC 80%SOC
电池冷却方式 Battery Cooling Mode 液冷Liquid Cooling 液冷Liquid Cooling
换电 Swapping battery 不支持Not Supported 不支持Not Supported
电池能量(kwh) Battery capacity (kWh) 67 67
电池包能量密度
(Wh/kg)
Battery Energy Density
(Wh/kg)
135 135
快充功率(kw) Fast Charge Power (kw) 80 80

前悬架类型 Front Suspension Type 麦弗逊式独立悬架
Mcpherson Independent
Suspension
麦弗逊式独立悬架
Mcpherson Independent
Suspension
后悬架类型 Rear Suspension Type 多连杆式独立悬架
Multi-Link Independent
Suspension
多连杆式独立悬架
Multi-Link Independent
Suspension
转向助力类型 Steering Type 电动助力Electric Power
Steering
电动助力Electric Power
Steering
前制动器类型 Front Brake Type 通风盘式Vented Disc 通风盘式Vented Disc
后制动器类型 Rear Brake Type 盘式 Disc 盘式Disc
驻车制动器类型 Parking Brake Type 电子驻车Electrical Parking
Brake
电子驻车Electrical
Parking Brake
前轮胎规格 Front Tyre ●235/50 R19
○235/45 R20
●235/50 R19
○235/45 R20
后轮胎规格 Rear Tyre ●235/50 R19
○235/45 R20
●235/50 R19
○235/45 R20
备胎规格 Spare Tyre

制动力分配
(EBD/CBC等)
Electronic Brake Force
Distribution(EBD/CBC,
etc.)
刹车辅助
(EBA/BAS/BA等)
Brake Assist
(EBA/BAS/BA, etc.)
牵引力控制
(ASR/TCS/TRC等)
Traction Control
(ASR/TCS/TRC etc.)
ABS防抱死 ABS
车身稳定系统
(ESC/ESP/DSC等)
Electronic Stability
Control(ESC/ESP/DSC,
etc.)
并线辅助 (BSD) Blind Spot Detection
 (BSD)
车身偏离预警系统
 (LDWS)
Lane Departure Warning
System
车道保持辅助系统
 (LKAS)
Lane keeping Assistance
Systems
车道居中保持
 (LCC)
Lane Centering Control
道路交通标识识别
 (TSR)
Traffic Sign
Recognition
主动刹车/主动安全
系统 (AEB)
Autonomous Emergency
Braking
DOW开门预警 Door Open Warning
前方碰撞预警
 (FCW)
Forward Collision
Warning
后方碰撞预警
 (RCW)
Rear Collision Warning
前/后驻车雷达 Front /Rear Parking
Sensor
前●/后●  Front/Rear 前●/后●  Front/Rear
驾驶辅助影像 Driving Assistance
○360度全景影像  360 -
degree Panoramic Image
○360度全景影像  360 -
degree Panoramic Image
巡航系统 Cruise Control System ○全速自适应巡航Full Speed
Range Adaptive Cruise
Control
○全速自适应巡航Full
Speed Range Adaptive
Cruise Control
驾驶模式切换 Driving mode ●运动 Sport
●经济Economy
●标准/舒适
Standard/comfortable
●运动 Sport
●经济Economy
●标准/舒适
Standard/comfortable
自动泊车入位 APA
制动能量回收系统 Braking Energy Recovery
System
自动驻车 Auto Hold
上坡辅助 Hill-start Assist
Control
辅助驾驶系统 ADAS ○L2 ○L2

中控彩色屏幕 IVI ●TFT ●TFT
卫星导航系统 GPS ●GPS ●GPS
导航路况信息显示 Navigation
道路救援呼叫
 (E Call)
E-CALL
蓝牙/车载电话 BLE
语音识别控制系统 SDS ○多媒体系统 ●多媒体系统
车联网 IOV
4G/5G网络 4G/5G 4G 4G
支持OTA OTA
WIFI热点 WIFI
多媒体/充电接口 Multimedia/Charging
port
●USB
●Type-C
●USB
●Type-C
USB/Type-C接口数量 Number of USB/Type-C ●前排2个/后排2个Two in
the Front/two in the Back
●前排2个/后排2个Two in
the Front/two in the Back
扬声器数量 Number of Speakers 4喇叭
4 speaker
8喇叭
8 speaker
全液晶仪表盘 LCD Instrument
事故数据记录 (EDR) EDR
手机无线充电功能 WPC
电池预加热 Battery Pre-heating PTC液冷液热的电池包
 Water PTC
PTC液冷液热的电池包
Water PTC
对外放电 Reverse charging
低速行车警告 AVAS

天窗类型 Sunroof Type ○不可开启全景天窗
Panaramic sunroof
○不可开启全景天窗
Panaramic sunroof
轮圈材质 Wheel material ●铝合金Aluminum Alloy ●铝合金Aluminum Alloy
电动后备箱 EGT
近光灯灯源 Low Beam Type LED LED
远光灯灯源 High Beam type LED LED
LED日间行车灯 LED Daytime Lamps
自动头灯 Automatic headlights
大灯高度可调 Headlight adjustable
大灯延时关闭 Follow Me Home
外后视镜功能 Ext Rearview Mirror
Function
●电动调节Electric
Adjustment
○电动折叠Electric Folding
●后视镜加热Heating the
Rearview Mirror
○锁车自动折叠 Automatic
Folding after locking the
Car
●电动调节Electric
Adjustment
●电动折叠Electric
Folding
●后视镜加热Heating the
Rearview Mirror
●锁车自动折叠 Automatic
Folding after locking the
Car
后雨刷 Rear Wiper
自动雨刮功能 Automatic Wiper
前后拖车钩 Front and Rear Tow
Hooks
防盗 IMMO ● 转向管柱steering column
、 VCU/BCM
● 转向管柱steering
column、VCU/BCM
车前雾灯 Front Fog Lamp
车后雾灯 Rear Fog Lamp

方向盘材质 Steering Wheel Material ●皮质Leather ●皮质Leather
方向盘位置调节 Steering Wheel Position
Adjustment
●手动上下+前后调节
Manually Up and Down +
Front and Rear Adjustment
○电动上下+前后调节
Electric Up and Down +
Front and Rear Adjustment
换挡形式 Shift Mode 电子旋钮换挡 EKS 电子旋钮换挡 EKS
多功能方向盘 Multifunctional
Steering Wheel
车内中控锁 Central Door Lock
阅读灯 Reading Lamp
车内环境氛围灯 Ambient Light ○多色multicolor ●多色multicolor
前/后电动车窗 Front/Rear Electric
Window
前●/后●  Front/Rear 前●/后●  Front/Rear
车窗一键升降功能 Glass one key Lift ●全车 the Whole Car ●全车 the Whole Car
车窗防夹手功能 Windows with Anti-
clamping function
内后视镜功能 Int Rearview Mirror
Function
●手动防炫目Manually Anti-
Glare
●手动防炫目Manually
Anti-Glare
车内化妆镜 Vanity Mirror ●主驾驶+照明灯Main driver
+ Lighting
●副驾驶+照明灯Co-pilot +
Lighting
●主驾驶+照明灯Main
driver + Lighting
●副驾驶+照明灯Co-pilot +
Lighting
行李箱灯 Trunk Light
12V电源 12V Power

空调温度控制方式 A/C Control Mode ●自动空调 Automatic Air
Conditioning
●自动空调 Automatic Air
Conditioning
后座出风口 Rear Vent
温度分区控制 Temperature Zoning
Control
双分区 Dual 双分区 Dual
后排空调控制面板 Rear vent Control Panel  -  -
车载空气净化器 Car Air Purifier
车内PM2.5过滤装置 PM2.5 Filter

钥匙类型 Key Type ●遥控钥匙 Remote Key ●遥控钥匙 Remote Key
无钥匙启动系统 PEPS-Start
无钥匙进入系统 PEPS-Access ●驾驶位 Driver's seat ●驾驶位 Driver's seat

座椅面料  Seat Fabric ●织物 Textile
○仿皮 (或PVC) Imitation
Leather(or PVC)
●织物 Textile
○仿皮 (或PVC) Imitation
Leather(or PVC)
驾驶座 Driver's Seat function ●8向 电动调节 (升降4向)
8-Way Electric adjustment
(4-Way up,4-Way down)
○电动腰托 (气袋,4向)
Electric waist support (4-
way air bag)
●乘员检测Crew Inspection
○座椅记忆功能(迎宾)  Seat
memory function (welcome
guests)
●8向 电动调节 (升降4向)
8-Way Electric adjustment
(4-Way up,4-Way down)
○电动腰托 (气袋,4向)
Electric waist support
(4-way air bag)
●乘员检测Crew Inspection
●座椅记忆功能(迎宾)
Seat memory function
(welcome guests)
副驾驶座 Front Seat ●4向 电动调节4-Way
Eletric Adjustment
●乘员检测Crew Inspection
●4向 电动调节4-Way
Eletric Adjustment
●乘员检测Crew Inspection
后头枕可调节 Rear Headrest
Adjustable
●后头枕可调节 (上下)
Adjustable Rear Headrest
(up and down)
●后头枕可调节 (上下)
Adjustable Rear Headrest
(up and down)
后排座椅 Rear Seat ●3人四六分式、带中央扶手
、 带杯托The Proportion is
4 and 6 for Three People,
with Central Armrest and
Cup Holder
●固定方式-椅背锁Fixing
mode - Seat back lock
●后头枕可调节 (上下)
Adjustable Rear Headrest
(up and down)
●一体式座垫One-piece Seat
Cushion
●3人四六分式、带中央扶手
、 带杯托The Proportion is
4 and 6 for Three People,
with Central Armrest and
Cup Holder
●固定方式-椅背锁Fixing
mode - Seat back lock
●后头枕可调节 (上下)
Adjustable Rear Headrest
(up and down)
●一体式座垫One-piece
Seat Cushion

安全气囊 Air Bag ●驾驶位气囊DAB
●副驾驶位气囊PAB
●侧气囊SAB
●侧气帘 (前后排带保压)
CAB
●驾驶位气囊DAB
●副驾驶位气囊PAB
●侧气囊SAB
●侧气帘 (前后排带保压)
CAB
前排安全带 Front Seat Belt ●安全带高度可调Seat Belt
Height is Adjustable
●限力 Force Limited
●安全带高度可调Seat Belt
Height is Adjustable
●限力 Force Limited
后排安全带 Rear Seat Belt ●3点式 Three-point Type
●中间三点式安全带 (靠背
上) Middle Three-point
Seat Belt (on the back)"
●3点式 Three-point Type
●中间三点式安全带 (靠背
上) Middle Three-point
Seat Belt (on the back)"
后排儿童座椅 Rear Child Seat ●儿童座椅固定装置ISOFIX ●儿童座椅固定装置ISOFIX
前排安全带未系提
Front Seat Belt
Reminder
●声音+指示灯Sound +
Indicator
●声音+指示灯Sound +
Indicator
后排安全带未系提
Rear Seat Belt Reminder ●声音+指示灯Sound +
Indicator
●声音+指示灯Sound +
Indicator
酒精锁接口 Alcolock interface
疲劳驾驶提示
 (DFMS)
DFMS
Remarks : Marking ● is the standard configuration,
Mark ○ is the optional configuration.
This specification is for reference only, please confirm with the actual vehicle of Dongfeng Motor Co., Ltd. Any changes to the information provided are subject to the latest version.
other  Secondary parameters The parts and components are constantly updated in production. The above parameters are only for reference and are mainly based on actual vehicles. The core parameters and configuration remain unchanged.
OEM customization  Wuhan Junfeng Automobile Co., Ltd.
